AK 48
The Ak-48 is a high quality, unique, folding crossbow.
It is manufactured with the best qualities take from Russian Weapon Art.
The Ak-48 is a superb combination of the best attributes and
features of both recurve style and compound crossbows.
-----------------------------------------------------
The integral hinged cocking lever ("Goat's Foot")
is the best mechanical cocking device available.
It allows cocking of the bow with a single hand and
provides a mechanical advantage of approximately 5:1.
Let off on the bow is approximately 60% effective.
A person of slight stature has the ability to cock
the bow with extremely high limb pound configurations.
The lever allows cocking the bow in less than perfect conditions,
because of it's extreme mechanical advantage.
Utilization of the lever also allows the string to be engaged
in the center of the latch allowing for supreme accuracy.
The limbs are of solid design and are manufactured with
advanced composite materials, used in the Russian aerospace industry.
They possess high elasticity, and resist splitting,
a common design fault of some of today's modern, high speed crossbows.
Draw weights can vary, depending on the customers choice of limbs (44 - 209 pounds).
Light poundage limbs can be utilized for informal target shooting and practice,
while the heavier choice of limbs can be used for the toughest
and largest of hunting game animals. Bolt velocities
can reach as high as 340 fps with the higher poundage limbs in place.
The limb tips are also of special design,
which allow the replacement of a bowstring without the use of a mechanical press.
The manufacture of the crossbow allows for quick assembly and disassembly.
The butt stock of the bow can be easily unfastened and the limbs are easily removed.
This allows for compact storage. For example,
the entire disassembled bow can be stored and transported in a case with measurements
of 50X15X30 inches The stock is handmade of natural fancy hardwoods.
The standard stock material is walnut, but other wood types can be utilized,
as available, and as specified by the customer.
The track or barrel of the bow is milled from an integral piece
of aluminum alloy which results in absolute accuracy and reliability.
The latch of the AK-48 is "unique".
It is a "revolutionary design" that is produced from the finest of tempered steels.
The trigger mechanism is of superior quality and release is extremely crisp and predictable.
The sight bridge boasts both horizontal and vertical adjustments.
The steel bridge allows for secure and maintenance free sight mounting.
Характеристики:
Wide: 32 inches
Length: 33.5 inches
High: 8,5 inches
Length of the track: 14 inches
String excursion: 11 inches
Limbs: high performance glass-composite materials
Velocity: 328 fps
Barrel: AL alloy
Latch: trigger tension 2 pounds
Stock: The standard stock material is redwood, but other wood types can be utilized
Arrows length: 11-21 inches, arrow weight 230-460 grains
Draw weight: up to 220 pounds
Mass Weight: 8,6 pounds
€2100
