Thunder n4250QE (S4985)
Tyan M4985
Product Description:
Tyan Processor Expansion Card for AMD Opteron™ Processor Solutions
Mfg. Part Number:
Tyan M4985
Features & Benefits:
The M4985 processor expansion card is the expansion board of Tyan Thunder n4250QE (S4985). You may upgrade four-way S4985 to eight-level processing platform through use of HT4881 and M4985 add-on modules.
Specifications:
Form Factor:
Dimension 12" x 13" with special architecture
Requires two HT4881 Hyper Transport™ connectors to mount on to the S4985
Processor:
Four AMD Opteron Socket F (1207-pin)
Support AMD Opteron™ (Rev. F) 8000 series processors
Four onboard 5-phase digital VRMs
Memory:
16x 240-pin DDR2 DIMM sockets (four per CPU), Dual channel memory bus
Support up to 64GB of Registered ECC DDR2 667/533/400 memory
Support four rank memory modules
Hardware Monitoring:
Two Analog Devices ADT7476 Hardware Monitoring IC
Six 4-pin fan headers support tachometer monitoring and speed control (PWM).
Temperature and voltage monitoring
Power Supply:
EPS 12V Power Supply
EPS12V/SSI v3.5 (24+8+8) power connectors
8 ცალი
Ordering Parts Number:
AMD OPN: OS8347PAL4BGE, Tray
Specifications:
Model: 8347 HE
Revision: BA
Core Count: 4
Core Speed (Mhz): 1900
Voltages: 1.15 V
Max Temps ©: 55°C to 71° C Amperage
Wattage: 55 W
L2 Cache Size (KB): 2048
L2 Cache Speed (Mhz): 1900
L2 Cache Count: 1
CMOS: 65nm SOI
Integrated Memory Controller Speed (Mhz): 1600
Socket: Socket F (1207)
ოპერატიულები 32 ცალი
Kingston ValueRAM 4GB DDR2 SDRAM Memory Module - 4GB (1 x 4GB) - 667MHz DDR2-667/PC2-5300 - ECC - DDR2 SDRAM - 240-pin - KVR667D2D4P5/4G
Baseboard Management Controller (BMC)
• Renesas H8 2167
Protocols and Standards
• Tailored for IPMI 2.0 compliance
• RMCP (Remote Management and Control
Protocol) & RMCP+ (RMCP Plus) *
• Alert Standard Forum (ASF)
* NOTE: RMCP+ can encrypt confidential remote configuration of parameters such user passwords and transfer of sensitive payload data over SOL.
Enhanced Authentication
• New algorithms provide more robust key
exchange process
Primary Communication Interface
• Keyboard Controller Style (KCS)
Auxiliary Communication Interface
• Intelligent Platform Management Bus (IPMB)
• Local Area Network (LAN)
Auxiliary SMBus / I2C buses
• 4 dedicated and independent buses available
for user expansion
Sensor Monitoring
• Voltage
• Temperature
• Tachometers
• Fan Speed Control / PWM
• Chassis Intrusion
Field Replaceable Unit (FRU)
• Chassis, motherboard, product, and other
information stored and secured in FRU
Form Factor
• 3.956" x 2.375" (100.48mm x 60.325mm)
• Low profile PCI form factor tailored to allow
different mounting varieties
- Fits on PCI slot
- Fits in 3.5" drive bay
- Fits inside almost any chassis .
ვიდეოკარტა Quadro FX 5600 4 ცალი ან NVIDIA Quadro Plex
ამაზე რას იტყვით? ? ?
This post has been edited by kwawI on 16 Apr 2008, 21:28
